SPA-10M-50 Series Broadband SSPA

Saluki SPA-10M-50 is a solid-state RF power amplifier with an output frequency of 10MHz to 50GHz and an output power of 1WIts power output is efficient and reliable. The product has functions such as temperature and current detection, alarm protection and so on.

The broadband solid state power amplifier is mainly used for testing and measuring instruments, Communication or interference, aviation control and other fields.

Key Features

Multi-octave broadband performance

High output power

Wide dynamic range

Low power consumption

Low spurious signal

Extremely load-resistant

Internal control, monitoring and protection circuit

CE, RoHS certification

Frequency Range

10MHz – 50GHz

Output Power

•   30dBm (typ.) @10MHz-20GHz

•   22dBm (typ.) @20-50GHz

Small Signal Gain

•   54dB (typ.) @10MHz-20GHz

•   46dB (typ.) @20-50GHz

Gain Flatness

•   ±6dB (max.) @10MHz-20GHz

•   ±5dB (max.) @20-50GHz

Input Power

•   -10dBm (max.) @10MHz-20GHz

•   -15dBm (max.) @20-50GHz


-60dBc (max.)

Input VSWR

2:1 (typ.)


50 ohm

Input Port

2.4mm (female)

Output Port

2.4mm (female)


245.5 × 255 × 87.1 mm

Power Supply

AC 220V±10%, 50/60Hz

Cooling Type

Air cooling

Operating Temperature

0 to 50℃

Main Machine

Module No. Item Description
SPA-10M-50-1 Solid State Power Amplifier 10MHz to 50GHz, output power 1W
Saluki Technology
