SARP-6 RF Acquisition Record and Playback Instrument

Saluki SARP-6 RF Signal Acquisition Record and Playback Apparatus is a portable RF signal acquisition record playback equipment. It can be used to directly acquire, record, and playback RF signal from 1MHz to 6GHz. Its data recording and bandwidth playback can reach 200MHz. The SARP-6 RF Signal Acquisition Record and Playback system is composed of up and down inverter module, high-performance ADC and DAC, and large capacity solid-state FLASH or high-performance disk. It is widely used in radar, GPS, communication, telemetry, as well as many other circumstances for civil purposes when acquiring signal and recording it down.

Applications: Interference Analysis/Surveillance/Spectrum Management/Satellite Communications

Key Features

Digital persistence spectrum monitoring

Replaceable and customizable PXI RF module

Graphical interface storage and player, Data management Software

Input signal frequency range 1MHz - 6GHz

Signal acquisition bandwidth up to 200MHz

Signal playback bandwidth up to 200MHz

Acquisition and playback speed up to 1GB/s

Data recording and playing capacity up to 8TB

Flip-down portable chassis, 17'' LCD monitor, resolution up to 1280*1024

When recording different bandwidths, recording time can be expanded dynamically

Capable of installing a strong Tektronix SignalVu Signal Analysis Software to analyze all the data after it is saved and stored.

Support NTFS binary file format, support for conversion to Matlab data files (.mat) and Tektronix Signal Vu file formats (.TIQ)

1. Signal Acquisition
Frequency Range

1MHz to 6GHz (other frequency bands can be customized)

Frequency Tuning Step Size

1kHz

Maximum Input of Signal Power

•   -10dBm (Normal Mode) / +10dBm (Anti-burn)

•   -30dBm (Low Noise Mode) / +10dBm (Anti-burn)

Gain Tunning Range

•   -10 to +40dB (Normal Mode)

•   0 to +50dB (Low Noise Mode)

Gain Control Step

0.5dB

Input Noise Figure

≤10dB (During Low Noise Mode)

Inband Clutter Suppresion

≥ 55dBc

Phase Noise (1GHz)

≤-95dBc/Hz@10KHz (Standard),  ≤-115dBc/Hz@10KHz (LP)

Acquisition Signal Bandwidth

110MHz (S300) / 200MHz (S480)

Acquisition Clock Frequency

300MHz (S300) / 480MHz (S480)

Data Recording Speed

As high as 1GB/s

Data Recording Capacity

As high as 8TB (Internal) / 48TB (External)

2. Signal Playback
Frequency Range

1MHz to 6GHz (other frequency bands can be customized)

Frequency Tunning Step Size

1kHz

Power Output Range

-60dBm to +13dBm

Power Output Tunning Step Size

0.5dB

Harmonic Suppresion

≥20dB (during 0dBm output)

Clutter Suppresion

≥60dBc (under the cirsumstances of single carrier output)

Phase Noise (1GHz)

≤-95dBc/Hz@10KHz (Standard)

Signal Playback Bandwidth

110MHz (P600) / 200MHz (P960)

Playback Clock Frequency

600MHz (P600) / 960MHz (P960)

Internal Reference Frequency

10MHz

Power Supply

100-240 VAC; 50/60 Hz

Power

Max. 250W

Dimension

425 (L) × 338 (W) × 230 (D) mm

Weight

Approx. 20kg

(Note: see more detail information in the ‘Resource’ – ‘Datasheet’)

Standard

Module No. Item Description
SARP-6-PL Portable record playback instrument platform i7 processor, 4GB memory, 256GB solid-state drive
SARP-DC-6 Downconverter 600MHz to 6GHz
SARP-S1-S300 Acquisition sample rate 300MSPS (110MHz bandwidth), 14-bit A/D
SARP-SSD2 Internal storage Standard capacity of 2TB
/ SignalBoxManager Data acquisition playback management software, with spectrum monitoring ability

Optional

Module No. Item Description
SARP-6-PH Portable record playback instrument platform i7 processor, 4GB memory, 512GB solid-state drive
SARP-UC-6 Upconverter 600MHz to 6GHz
SARP-DC-LF Downconver extension Downconverter frequency range expansion to: 1MHz - 6GHz
SARP-UC-LF Upconver extension Upconverter frequency range expansion to: 1MHz - 6GHz
SARP-LP Low phase noise Noise figure input ≤10dB
SARP-S1-S300 Acquisition option Sample rate 300MSPS (110MHz bandwidth), 14-bit A/D
SARP-P1-P600 Playback option Sample rate 600MSPS (110MHz bandwidth), 16-bit D/A
SARP-S1-S500 Acquisition option Sample rate 500MSPS (200MHz bandwidth), 14-bit A/D
SARP-P1-P1000 Playback option Sample rate 1000MSPS (200MHz bandwidth), 16-bit D/A
SARP-SSD2 Internal storage Capacity of 2TB
SARP-SSD4 Internal storage Capacity of 4TB
SARP-SSD8 Internal storage Capacity of 8TB
SARP-SAS48 Internal storage Capacity of 48TB
SARP-10Gb Dual port Gigabit network data interface /
/ SignalBoxManagerplayback management software Data acquisition playback management software, with spectrum monitoring ability
/ SignalOverView Signal file quick-view software
