SLNA15273Z is a wideband low noise RF coaxial amplifier covering frequency from 15GHz to 27GHz. The amplifier offers 41dB typical high gain, 2.5dB typical noise figure and +28dBm typical output power of P1dB.
Saluki’s RF amplifier brings compact and reliable gain block performance to MW&RF designers, wireless infrastructure, and systems integrators.
Unit Price: US$ 2,860
Click here to purchase online !
(Note: send email to sales@salukitec.com for more modules)
Ultra wide band operation 15GHz - 27GHz
Gain: 41dB typical
Noise figure: 2.5dB typical
P1dB output power: +28dBm typical
Supply voltage: +12V @ 450mA
50 ohm matched input / output
| Frequency Range | 15 GHz to 27 GHz |
| Gain | 41 dB (typ.) |
| Gain Flatness | ± 2.0 dB |
| Noise Figure | 2.5 dB (typ.) |
| Input VSWR | 1.8:1 (typ.) |
| Output VSWR | 2.0:1 (typ.) |
| Output 1dB Compression Point (P1dB) | 28 dBm (typ.) |
| Saturated Output Power (Psat) | 29 dBm (typ.) |
| Output Third Order Intercept (OIP3) | 36 dBm (typ.) |
| Supply Current | +12V @ 450mA (typ.) |
| Isolation S12 | -65 dB |
| Connector | 2.92mm (female) |
| Finish | Gold plated |
| Material | Copper |
| Size | 30 (L) × 40 (W) × 10 (H) mm |
| Weight | Maximum 3.5 ounces |
(Note: see more detail information in the ‘Resource’ – ‘Datasheet’) |
| Module No. | Item | Description |
| SLNA15273Z | Low Noise Amplifier | 15 to 27GHz, Gain 41dB, SMA (female) |
