82407 Series SA Frequency Extension Module

82407 series spectrum analyzer frequency extending module products are designed for millimeter wave spread spectrum measurement of signal/spectrum analyzer. This series frequency extending module can also be used as the front end of millimeter wave signal receiver.

The standard rectangle waveguide of corresponding band is used for the input interface of 82407 series frequency extending module. 2.4mm and SMA female coaxial adapters (3.5mm coaxial adapters are used for 82407R LO input and IF output) are used for LO input and IF output respectively.

Key Features

The average noise level is as low as -140dBm/Hz

Maximum outline dimension is less than 72mm×26mm×112mm (82407/NB/A/B/C/D), 120mm× 85mm×240mm (82407R)

The smart USB interface is used to interconnect with the host, so as to enable automatic identification of spread spectrum module and automatic configuration of frequency conversion loss and other functions

82407 Module

•   Output frequency range: 50GHz – 75GHz

•   Harmonic number: 5

•   Frequency conversion loss: 28dB (max.)

•   Average noise level: -132dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 20dBm (max.)

•   RF input interface: WR15/UG385U

82407NB Module

•   Output frequency range: 60GHz – 90GHz

•   Harmonic number: 6

•   Frequency conversion loss: 28dB (max.)

•   Average noise level: -132dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 20dBm (max.)

•   RF input interface: WR12/UG387U-M

82407A Module

•   Output frequency range: 75GHz – 110GHz

•   Harmonic number: 7

•   Frequency conversion loss: 32dB (max.)

•   Average noise level: -130dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 20dBm (max.)

•   RF input interface: WR10/UG387U-M

82407B Module

•   Output frequency range: 110GHz – 170GHz

•   Harmonic number: 9

•   Frequency conversion loss: 38dB (max.)

•   Average noise level: -120dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 20dBm (max.)

•   RF input interface: WR6/UG387U-M

82407C Module

•   Output frequency range: 170GHz – 220GHz

•   Harmonic number: 7

•   Frequency conversion loss: 42dB (max.)

•   Average noise level: -115dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 20dBm (max.)

•   RF input interface: WR5/UG387U-M

82407D Module

•   Output frequency range: 220GHz – 325GHz

•   Harmonic number: 9

•   Frequency conversion loss: 50dB (max.)

•   Average noise level: -110dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 20dBm (max.)

•   RF input interface: WR3/UG387U-M

82407R Module

•   Output frequency range: 325GHz – 500GHz

•   Harmonic number: 24

•   Frequency conversion loss: 30dB (max.)

•   Average noise level: -140dBm/Hz (max.)

•   LO power range: 8 – 12dBm

•   RF input power: 25dBm (max.)

•   RF input interface: WR2.2/UG387U-M

Power Consumption

82407/NB/A/B/C/D: ≤5W;

82407R: ≤30W

Environmental Adaptability

Comply with specified requirements of Level 3 equipment in GJB3947A-2009

Interface

•   RF interface: Standard rectangular waveguide outlet

•   IF interface:SMA (female), 50Ω

•   82407/NB/A/B/C/DLO interface: 2.4mm coaxial (female), 50Ω

•   82407R LO interface: 3.5mm coaxial (female), 50Ω

•   Communication interface: Mini USB (female, USB2.0)

Dimension

82407/NB/A/B/C/D: 72 (W) × 26 (H) × 112 (D) mm

82407R: 120 (W) × 85 (H) × 240 (D) mm

Weight

82407/NB/A/B/C/D: ≤400g

82407R: ≤5kg

Main Machine

Module No. Item Description
82407 Spectrum Analyzer Frequency Extending Module Frequency range: 50 GHz to 75 GHz
82407NB Spectrum Analyzer Frequency Extending Module Frequency range: 60 GHz to 90 GHz
82407A Spectrum Analyzer Frequency Extending Module Frequency range: 75 GHz to 110 GHz
82407B Spectrum Analyzer Frequency Extending Module Frequency range: 110 GHz to 170 GHz
82407C Spectrum Analyzer Frequency Extending Module Frequency range: 170 GHz to 220 GHz
82407D Spectrum Analyzer Frequency Extending Module Frequency range: 220 GHz to 325 GHz
82407R Spectrum Analyzer Frequency Extending Module Frequency range: 325 GHz to 500 GHz

Options

Module No. Item Description
82407-H01 2.4mm RF test cable Connect host LO output port and LO input port of frequency extending module (Required option)
82407-H02 SMA RF test cable Connect host IF input port and IF output port of frequency extending module (Required option)
82407-H03 Adapter 2.4mm to 3.5mm adapter for 82407R
