SLNA0P1184Z is a wideband low noise RF coaxial amplifier covering frequency from 0.1GHz to 18GHz.
Saluki’s RF amplifier brings compact and reliable gain block performance to MW&RF designers, wireless infrastructure, and systems integrators.
Low Noise Amplifier, 0.1 to 18GHz, 32dB, SMA(f)
Key Features
Gain: 32dB typical
Noise figure: 2.2dB typical
P1dB output power: +26dBm typical
Supply voltage: +12V @ 320mA
50 ohm matched input / output
Application
Wireless infrastructure
5G communication
Test and measurement instrument
US$ 2,873 (1-5pcs)
NOTICE: Online purchases are temporarily closed. Sorry for the inconvenience.
- Download
- SLNA0P1184Z Datasheet
-
Select Module
[wp_cart_button name=”SLNA0P1184Z Low Noise Amplifier” price=”2873″ shipping=”50″ var1=”Low Noise Amplifier|SLNA0P1184Z”]
[show_wp_shopping_cart]
Add to Cart
Detailed
Technical Specifications
| Parameter | Min. | Typ. | Max. | Min. | Typ. | Max. | Units |
| Frequency Range | 0.1 – 10 | 10 – 18 | GHz | ||||
| Gain | 28 | 32 | 36 | 28 | 30 | 36 | dB |
| Gain Flatness | ±2.0 | ±2.0 | dB | ||||
| Gain Variation Over Temperature | ±1.0 | ±1.5 | dB | ||||
| Noise Figure | 2.2 | 4.5 | 2.8 | 4.0 | dB | ||
| Input VSWR | 1.8 | 1.8 | :1 | ||||
| Output VSWR | 1.8 | 1.8 | :1 | ||||
| Output 1dB Compression Point (P1dB) | 23.5 | 26 | 20 | 22 | dBm | ||
| Saturated Output Power (Psat) | 28 | 24 | dBm | ||||
| Output Third Order Intercept (OIP3) | 35 | 32 | dBm | ||||
| Supply Current (Vcc=+12V) | 320 | 400 | 320 | 400 | mA | ||
| Isolation S12 | -60 | -55 | dB | ||||
| Connector | SMA (female) | ||||||
| Finish | Gold plated | ||||||
| Material | Aluminum | ||||||
| Sealing | Epoxy sealed (standard), Hermetically sealed (optional) | ||||||
(See more specifications in the “Datasheet”)
